HP Compaq 8000 Elite PC Product Specifications



































HP Compaq 8000 Elite PC Product Specifications


Product features

Feature
Description
Chipset
Intel Q45 Express
Processor and Speed
Intel Celeron Processors:
  • Intel Celeron E3200 Processor 2.40-GHz, 1M L2 cache, 800 MHz FSB
  • Intel Celeron E3300 Processor 2.50-GHz, 1M L2 cache, 800 MHz FSB
Intel Pentium Processors:
  • Intel Pentium E5300 Processor 2.60-GHz, 2M L2 cache, 800 MHz FSB
  • Intel Pentium E5400 Processor 2.70-GHz, 2M L2 cache, 800 MHz FSB
  • Intel Pentium E6300 Processor 2.80-GHz, 2M L2 cache, 1066 MHz FSB
  • Intel Pentium E6500 Processor 2.93-GHz, 2M L2 cache, 1066 MHz FSB
Intel Core 2 Duo Processors:
  • Intel Core 2 Duo E7500 Processor 2.93-GHz, 3M L2 cache, 1066 MHz FSB
  • Intel Core 2 Duo E7600 Processor 3.06-GHz, 3M L2 cache, 1066 MHz FSB
  • Intel Core 2 Duo E8400 Processor 3.0-GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
  • Intel Core 2 Duo E8500 Processor 3.16-GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
  • Intel Core 2 Duo E8600 Processor 3.33-GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
Intel Core 2 Quad Processors:
  • Intel Core 2 Quad Q8400 Processor 2.66-GHz, 4M L2 cache, 1333 MHz FSB (SFF) (CMT)
  • Intel Core 2 Quad Q8400s Processor (low power) 2.66-GHz, 4M L2 cache, 1333 MHz FSB
  • Intel Core 2 Quad Q9505 Processor 2.83-GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology (SFF) (CMT)
  • Intel Core 2 Quad Q9505s Processor (low power) 2.83-GHz, 6M L2 cache, 1333 MHz FSB with vPro Technology
  • Intel Core 2 Quad Q9550 Processor 2.83-GHz, 12M L2 cache, 1333 MHz FSB with vPro Technology (SFF) (CMT)
  • Intel Core 2 Quad Q9550s Processor (low power) 2.83-GHz, 12M L2 cache, 1333 MHz FSB with vPro Technology
  • Intel Core 2 Quad Q9650 Processor 3.0-GHz, 12M L2 cache, 1333 MHz FSB with vPro Technology (SFF) (CMT)
System Memory
  • 1GB DDR3 SDRAM PC3-10600 (1,333-MHz) Non ECC (1 x 1GB)
  • 2GB DDR3 SDRAM PC3-10600 (1,333-MHz) Non ECC (1 x 2GB)
  • 2GB DDR3 SDRAM PC3-10600 (1,333-MHz) Non ECC (2 x 1GB)
  • 4GB DDR3 SDRAM PC3-10600 (1,333-MHz) Non ECC (1 x 4GB)
  • 4GB DDR3 SDRAM PC3-10600 (1,333-MHz) Non ECC (2 x 2GB)
  • 8GB DDR3 SDRAM PC3-10600 (1,333-MHz) Non ECC (2 x 4GB)
  • 8GB DDR3 SDRAM PC3-10600 (1,333-MHz) Non ECC (4 x 2GB) (SFF) (CMT)
  • 16GB DDR3 SDRAM PC3-10600 (1,333-MHz) Non ECC (4 x 4GB) (SFF) (CMT)
Hard Drives
  • 160GB 2.5 in Hard Disk Drive 7,200 rpm, 8MB cache, 3.0GB/s, NCQ, Smart IV (USDT)
  • 160GB 3.5 in Hard Disk Drive 7,200 rpm, 8MB cache, 3.0GB/s, NCQ, Smart IV (SFF)(CMT)
  • 160GB 2.5 in Hard Disk Drive 10,000 rpm, 16MB cache, 3.0GB/s, NCQ, Smart III (SFF)(CMT)
  • 160GB Removable Hard Disk Drive 7,200 rpm, 8MB cache, 3.0GB/s, NCQ, Smart IV (SFF)(CMT)
  • 250GB 2.5 in Hard Disk Drive 7,200 rpm, 8MB cache, 3.0GB/s, NCQ, Smart IV (USDT)
  • 250GB 3.5 in Hard Disk Drive 7,200 rpm, 8MB cache, 3.0GB/s, NCQ, Smart IV (SFF)(CMT)
  • 250GB Removable Hard Disk Drive 7,200 rpm, 8MB cache, 3.0GB/s, NCQ, Smart IV (SFF)(CMT)
  • 500GB 3.5 in Hard Disk Drive 7,200 rpm, 16MB cache, 3.0GB/s, NCQ, Smart IV (SFF)(CMT)
  • 500GB Removable Hard Disk Drive 7,200 rpm, 16MB cache, 3.0GB/s, NCQ, Smart IV (SFF)(CMT)
  • 1 TB 3.5 in Hard Disk Drive 7,200 rpm, 16MB cache, 3.0GB/s, NCQ, Smart IV (SFF)(CMT)
Solid State Drives
64GB 2.5 in Solid State Drive
5.25 in Optical Drives
  • DVD-ROM Drive (SFF)(CMT)
  • SuperMulti LightScribe DVD Writer Drive (SFF)(CMT)
  • Blu-Ray Writer Drive (SFF)(CMT)
Slimline Optical Drives
  • DVD-ROM Drive (USDT)
  • SuperMulti LightScribe DVD Writer Drive (USDT)
Media Card Readers
  • Media Card Reader (22-in-1) (SFF)(CMT)
  • Media Card Reader (22-in-1) with 1394 port (SFF)(CMT)
  • Secure Digital (SD) HC Reader (USDT)
Network Interface Connection
  • Intel 82567LM GbE Network Connection (integrated)
  • Intel Pro 1000 CT GbE NIC (PCIe x1) (SFF)(CMT)
  • Broadcom NetXtreme GbE Ethernet Plus NIC (PCIe x1) (SFF)(CMT)
NOTE:
The integrated network connection is required to support the vPro Technology features.
  • HP 802.11 b/g/n Wireless NIC (PCIe x1) (SFF) (CMT)
  • Intel Wi-Fi Link 5100 a/b/g/n Wireless NIC (mini PCI) (USDT)
NOTE:
These wireless network interface solutions will disable the vPro Technology features.
Modem
LSI Hi-Speed 56K International Soft Modem (PCIe x1) (SFF)(CMT)
Keyboard/Mouse
Keyboard:
  • PS/2 Standard Keyboard
  • USB Standard Keyboard
  • USB SmartCard Keyboard
  • USB Mini Keyboard
  • USB & PS/2 Washable Keyboard
Mouse:
  • PS/2 Optical Scroll Mouse
  • USB Optical Scroll Mouse
  • USB Laser Scroll Mouse
Graphics
  • Intel Graphics Media Accelerator 4500 (integrated)
  • Nvidia GeForce 3G210 Graphics Card (SFF)(CMT)
  • Nvidia Quadro NVS 290 Graphics Card (SFF)(CMT)
  • Nvidia Quadro NVS 295 Graphics Card (SFF)(CMT)
  • ATI Radeon HD 4650 DP Graphics Card (SFF)(CMT)
  • HP ADD2 SDVO + DVI-D Video Adapter (SFF)(CMT)
  • HP DisplayPort to DVI-D Adapter (SFF)(CMT)
  • HP DisplayPort to VGA Adapter (SFF)(CMT)
Power Supply
  • 240 W standard efficiency active PFC (SFF)
  • 320 W standard efficiency active PFC (CMT)

Audio/Visual

Features
Description
Audio/Visual
  • High Definition Audio with Realtek ALC261 codec (all ports are stereo)
  • Microphone/Headphone and dedicated headphone front ports
  • Line-out and Line-In rear Ports
  • Multi-streaming capable
  • Internal Speaker (standard)
  • HP Thin USB Powered Speakers

Communications

Features
Description
Communication
  • HP Wireless 802.11 b/g/n NIC Card
  • Broadcom NetXtreme GbE Ethernet Plus NIC Card
  • Intel Gigabit CT Desktop NIC Card
  • LSI Hi-Speed 56K Int'l Soft Modem Card
  • RJ11 Modem Adapter Kit
Graphics
  • Intel Graphics Media Accelerator 4500 (integrated)
  • Nvidia GeForce 3G210 Graphics Card (SFF)(CMT)
  • Nvidia Quadro NVS 290 Graphics Card (SFF)(CMT)
  • Nvidia Quadro NVS 295 Graphics Card (SFF)(CMT)
  • ATI Radeon HD 4650 DP Graphics Card (SFF)(CMT)
  • HP ADD2 SDVO + DVI-D Video Adapter (SFF)(CMT)
  • HP DisplayPort to DVI-D Adapter (SFF)(CMT)
  • HP DisplayPort to VGA Adapter (SFF)(CMT)

Physical Specifications

Features
Description
Chassis Dimensions (HxWxD)
Ultra-slim Desktop: 66 x 251.5 x 254 mm (2.6 x 9.9 x 10 in)
Small Form Factor: 100 x 338 x 378.5 mm (3.95 x 13.30 x 14.9 in)
Convertible Minitower: 447.8 x 177.8 x 444.5 mm (17.63 x 7.00 x 17.5 in)
System Weight
Ultra-slim Desktop: 3.07 kg (6.75 lb)
Small Form Factor: 7.6 kg (16.72 lb)
Convertible Minitower: 11.15 kg (24.54 lb)
Temperature
Operating: 10° to 35°C (50° to 95° F)
Non-operating: –30° to 60°C (–22° to 140° F)
NOTE:
Operating temperature is de-rated 1.0 deg C per 3000m (10000 ft) for SFF above sea level, no direct sustained sunlight. Maximum rate of change is 10 deg C/Hr for SFF. The upper limit may be limited by the type and number of options installed.
Humidity
Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Altitude
Operating: 3048 m (10,000 ft)
Non-Operating: 9144 m (30,000 ft )
Power
  • 240 W standard efficiency active PFC (SFF)
  • 320 W standard efficiency active PFC (CMT)
Security
  • IEEE and WiFi compliant 64 / 128 bit WEP encryption
  • AES: CCM
  • 802.1x authentication
  • WPA: 802.1x. WPA-PSK and TKIP
  • WPA2 certification
  • IEEE 802.11i
  • Cisco Certified Extensions, all versions through V5

Software overview

Feature
Description
Operating System
  • Genuine Windows Vista Business
  • Genuine Windows 7 Professional Edition
  • Windows XP Professional



* * ***
